Vértes Power Plant - Boiler peripheral biomass feeder system for boiler no. 1 at Oroszlány Power Plant

Vértes Power Plant - Boiler peripheral biomass feeder system for boiler no. 1 at Oroszlány Power Plant

任务:

Feeding of wood chips and energy cane at specific capacity, subject to the boiler’s different operating conditions.

The scope of supply ranged from conveyor belts no. 5/a and 5/b along the main power plant coal supply route – conversion of the discharge chute to a switch-plate chute – to the four feed chunks located on the side wall of the boiler. A new silo feeder, rubber belt conveyor with permanent rotational speed, a daily storage silo with 300 m3 useful volume and a rotary spreader and a discharge conveyor, and two chain scraper conveyor belts with frequency changer, and a permanent-speed weighing belt with electronic belt scale calibrated by the OMH [National Office of Measures, Hungary] were installed in the system.

The task of our Company was to implement the entire architectural, mechanical engineering, I&C and electric power transmission jobs in the project.

Customer Vértesi Erőmű Zrt.

Characteristics of the feeder system

Description wood chips energy cane Bulk density 0.269 t/m3 0.129t/m3 Fuel consumption 17.0 t/h 13.6 t/h

客户

Vértesi Erőmű Zrt.

地点

2841 Oroszlány
